THE PVC PIXEL WINDOW:

A NEW PROFILE WITH A 100% CONTEMPORARY DESIGN
FOR EXCEPTIONAL LUMINOSITY

Natural light is indispensable to us. Its benefits are countless: it improves morale, stimulates alertness, regulates the internal clock or synchronizes sleep.

To let this natural light flood into our interiors, OKNOPLAST, a European leader in PVC windows, doors and shutters, has put all its know-how into the design of a revolutionary new window with a contemporary, narrower profile (with a 70mm frame) and with enlarged clear glazing: the PIXEL

WITH THE PIXEL WINDOW, YOUR HOME BECOMES A DESIGN

With its exceptional design with angular shapes, the new PIXEL OKNOPLAST window responds to the latest architectural trends with more modern, unrounded shapes. Much more than a window, the PIXEL is a decorative and design element that sublimates the home.



THE PIXEL WINDOW:

To abolish the boundaries between inside and outside, this new OKNOPLAST window offers 22% more light than a standard window. Thanks to its slim central opening (112 mm wide), this pixel window brings great clarity to interiors.

This additional light supply, combined with remarkable thermal performance, not only guarantees well-being, but also a significant reduction in energy consumption.

THERMAL PERFORMANCE & ENERGY SAVINGS

The new PIXEL window is also very thermally efficient. The “Research and Development” teams at OKNOPLAST have improved its insulation capacity thanks to a 6-chamber profile and a 70 mm Class A chassis which guarantee sound protection and eliminate heat loss, air infiltration and condensation.



PIXEL WINDOW TECHNICALITY

On the glazing side, it is equipped as standard with reinforced thermal double glazing (4/16/4) with argon filling (insulating gas). The PIXEL window is also available in triple glazing (3/14/3/14/3) ensuring Ug coefficients at 0.6 W/m2K and Uw at 0.9 W/m2K. Thanks to the thermal performance of its glazing, it avoids heat loss and the effect of cold walls inside the home. This multi-room structure is the key to significant energy savings.

SECURITY FIRST AND FOREMOST

OKNOPLAST has equipped its new PIXEL window with a new generation of equipment designed to ensure the security of goods and persons: patented sash and frame reinforcements, double security point, burglar-proof glazing, as well as two security latches.

Latches which, by enclosing the mushroom-shaped roller when the window is closed, make it very difficult to remove the window with a crowbar. The resistance classes RC1 or RC2 are available as options.



THERMAL PERFORMANCES:

DOUBLE GLAZING 4/16/4

Ug: 0,26 BTU(th)/h•ft²•°F

Uw: 0,29 BTU(th)/h•ft²•°F

SHGC: 0,43

TRIPLE GLAZING 3/14/3/14/3

Ug: 0,12 BTU(th)/h•ft²•°F

Uw: 0,2 BTU(th)/h•ft²•°F

SHGC: 0,36

GET INSPIRED

See how windows and doors can transform a home and spark new design ideas. Explore our gallery of photos featuring OKNOPLAST windows and doors and imagine the possibilities.
