CR-EMD-A4W

Buy This Doors in Our Online Store
Use Promo Code: CRAFTWOOD to get 10% OFF


Our Euro Collection entry doors are made in Europe and deliver superior performance due to the latest European technology and highest level of designs and quality for exterior doors.

  • Model: CR-EMD-A4W
  • Design: Single
  • External Dimensions (inches):43-1/2 x 98 x 4-9/16 ,37-1/2 x 98 x 4-9/16
  • Wood/Finish:Mahogany Wood Veneer with Walnut Finish,Mahogany Wood Veneer with Espresso Finish

Shown in Mahogany Wood Veneer with Walnut Finish

CraftwoodProducts.com-exterior-doors-wood-doors-Glenview-Doors-Classic-Collection-DB-EMD-711W-Mahogany-Veneer-WalnutCraftwoodProducts.com-exterior-doors-wood-doors-Glenview-Doors-Classic-Collection-DB-EMD-711W-glass-popup

The Door Sandwich

Craftwoodproducts.com-Contemporary-Collection-Euro-Modern-Collection-Corner-Sample-Top-Side-ViewThe door sandwich design includes stiles and rails made from solid European wood, thermal insulation board – Styrodur C and layers of aluminum sheets and plywood in various wood veneers including Mahogany wood.
This design provides excellent thermal performance and overall product durability.

Pre-Hanging

Each door unit comes with full frames and doors panels to resist the elements and regular usage.

Each unit includes:

  • 4-9/16″, 5-1/4″ or 6-5/8″ Jambs (different sizes available upon request)
  • Compression Weather-Strip: Bronze or White
  • Sill: Bronze, Aluminum, Gold – Adjustable or Fixed Flat Oak
  • Hinges: 4″x4″ – Oil Rubbed Bronze, Satin Nickel, Bright Brass (different finishes available upon request)
  • Door Shoe: Bronze, Aluminum or Gold
  • Bore: Single or Double
  • Double Door: Include Aluminum or Wood “T” Astragal with Matching Flush Bolts
  • Brickmould and Optional Casing

Door Handing / Swing Configuration


Right Hand Active Outswing

Right Hand Active Inswing

Left Hand Active Outswing

Left Hand Active Inswing

Door Jamb

Craftwoodproducts.com-Door-Jamb

Jamb’s width
All our doors are pre-hung on primed or wood rabbeted jambs. The frame width must fit the exterior wall thickness.

Standard Jamb Widths: 4-5/8″, 5-1/4″, 6-5/8″
For custom size frames please call our experienced sales team at: 630.758.1740

Hinges

Craftwoodproducts.com-Hinges

  • Each Pre-hung comes with 4″x4″ ball bearing hinges.
  • 5 knuckles, 2 ball bearing
  • Full mortise
  • UL listed
  • Available in Steel, Brass and Stainless Steel

Door Sill (Threshold)

Protected your door system against air and water infiltration at its most vulnerable point with Adjustable Aluminum Threshold in Bronze, Aluminum or Brass Finish.
We also offer:

  • Bumper Outswing Sill (for high exposure areas and severe weather conditions)
  • ADA Compliant Sill

Craftwoodproducts.com-Door-Sill-Threshold

Weatherstrip

Craftwoodproducts.com-Weatherstrip-Q-lon

Interlock weather-stripping to provide a tight and continuous seal. Installed into kerf slot on the face of the door frame.
Available in Dark Bronze and White Finish.

Brickmould

Brickmoulding is used as decorative trim around the exterior of the door unit and where it meets the edge of brick.
Shipped loose on all square top units. All round top units come with brickmould attached to frame.
Standard size is 1-1/4″ x 2″.
craftwoodproducts.com-brickmould

Handle Preparation


All doors come with standard single bore preparation (2-3/8″ or 2-3/4″ backset).
If the door requires a separate deadbolt lock, than the door must be additionally bored at 5-1/2″ above to accommodate handle and deadbolt.

Deadbolt is drilled 5-1/2″ above the handle.
